Manual Double Head Cutting Machine 400 mm

Manual Double Head Cutting Saw with 400 mm blades for aluminum and PVC profiles. The head is moved manually and measured with a digital display, then fixed pneumatically for accurate cutting. Hydro-pneumatic movement supports precise cuts, saw speed is adjustable, and both heads can be angled right/left up to 45 degrees. Main angles 45 and 90 are fixed with vertical pneumatic clamps, and special intermediate fixing points are available for frequently used plus/minus 60, 67.5, and 75 degree angles. Protective covers improve operator safety.

  • Electricity Rating 400 V, 3~ 50-60 Hz
  • Total Power 4.4 kW
  • Power of Each Motor 2.2 kW
  • Saw Speed 3,000 rpm
  • Max. Cutting Dimension 3,450 mm
  • Min. Cut Size 470 mm
  • Air Pressure 6-8 Bar
  • Air Consumption 46 lt./min. (120 lt./min. with cooling system)
  • Machine Height 1700 mm
  • Machine Length 4100 mm
  • Machine Width 750 mm
  • Machine Weight 410 kg
  • Cutting Angle Range 45-135 degrees (manual intermediate settings)
  • Main Fixed Angles 45 and 90 degrees
  • Intermediate Fixing Points +/-60, +/-67.5, +/-75 degrees
